China Tshuab Npog Vacuum Sawv Ntawm Tus Tsim Khoom-

Tshuab Npog Vacuum Sawv Ntawm siv vacuum siab tsawg ua zog thauj kev sib cais khoom nrig thiab kua, ua kom ua hauj lwm tsis nres xyaum kev npog, kev ntxuav, kev qhuav, thiab kev rov ua hauj lwm ntawm ntaub npog. Cov khoom no muaj kev npog zoo siab, kev tsim khoom ntau, kev ntxuav zoo, kev ua yooj yim, thiab cov nqi kho tsawg.

Kev Sib Dhos Ncauj Vacuum

Kev sib dhos ncauj vacuum yog ib feem tseem ceeb ntawm tshuab npog vacuum sawv ntawm, feem ntau muaj ncauj npog roj hmab, lub xauv vacuum, cov log tsav, thiab chaw txais ncauj. Ncauj npog roj hmab yog txoj hauj lwm npog tseem ceeb, nws kev ua hauj lwm cuam tshuam ncaj qha rau kev npog zoo thiab tshuab ua hauj lwm zoo. Lub xauv vacuum ib txog sib kov ncauj npog, ua ib cheeb tsam vacuum adsorption ntawm dej ntse.

Txoj Kev Ua Hauj Lwm

Thaum ua hauj lwm, lois ua ntej muab zog ruaj khov los ntawm gearbox, tsav lub hnab npog voj voog tsis nres. Ntaub npog, uas tau muab tso saum ncauj npog ua ntej, tsiv sib timp ntawm ncauj, npaj rau kev sib cais khoom nrig thiab kua tom qab.

Thaum lub hnab npog voj voog ib txog sib kov ncauj npog thiab lub xauv vacuum, kev txuas lub xauv rau vacuum system sab nraud ua ib cheeb tsam vacuum adsorption ruaj khov saum ncauj—qhov tseem ceeb rau kev sib cais.

Tom qab ntawd, cov kua nrig yuav ua hauj lwm raug faib sib xws rau ntaub npog ntawm ib lub tshuab tshwj xeeb. Thaum nkag mus rau cheeb tsam vacuum adsorption, cov kua ntawm kua nrig liav dhau ntaub npog ntawm siab tsawg thiab nyob rau hauv lub xauv vacuum los ntawm cov kav rooftop saum ncauj npog. Ib txhib ntawd, cov khoom nrig hauv kua nrig raug ntaub npog nyob nres, soj ntsuam los ua ib qho khoom nrig.

Raws li ncauj npog txuas ntxiv tsiv, cov khoom nrig uas tau los txog tshuab kev ntxuav thiab kev qhuav rau kev kho zoo. Nyob rau hauv theem kawg ntawm txoj kev tsim khoom, ntaub npog cais rau lub hnab npog voj voog. Pab los ntawm discharge roller, cov khoom nrig roj hmab tau smoothly unloaded. Ntaub npog, ntxuav kom tshem cov khoom tsis zoo, rov qab mus saum ntaj ntawm lub hnab npog npog rau lub voj voog tom qab, ntseeg tau tias cov tshuab ua hauj lwm tsis nres.

Cov Yam Ntxim

Siv "vacuum adsorption tsis nres + modular design," cov tshuab muab cov zoo tseem ceeb hauv kev sib cais khoom nrig thiab kua:

1. Kev sib cais zoo siab nrog kev ua ruaj khov

Kev khij vacuum siab tsawg tsis nres hauv lub xauv vacuum ua kom cov kua npog ceev. Sib xyaw nrog kev ua hauj lwm sib xws ntawm ncauj npog, nws ua tiag tiag "feed-separation-discharge" ua hauj lwm tsis nres. Piv nraug nrog cov khoom xub dua xws li plate-and-frame filter presses, nws ua ntau khoom nrog cov khoom nrig qhuav ruaj khov (15%-30%), txo cov nqi tom kawg thiab pab kev tsim khoom loj.

2. Khoom Nrig Huv Si Thiab Kev Ntxuav Zoo

Ib cheeb tsam ntxuav tshwj xeeb siv kua ntxuav fwb uas liav tag nrho cov khoom nrig ntawm vacuum siab, ua tiag "displacement washing" nrog kev zoo tshij 99.8% nyob qho tshwj xeeb. Kev ntxuav coob theem txhim kho cov khoom tsis zoo, ua raws li kev xav tau huv si siab ntawm kev lag luam.

3. Kev Ua Yooj Yim Thiab Automation Siab

Tsav los ntawm cov lois + gearboxes, kev tswj PLC dynamically hloov ncauj ceev, vacuum siab, thiab lwm cov parameters nyob lub sij hawm tiag tiag, txo kev cuam tshuam los ntawm tus neeg. Ntaub npog tau自动 ntxuav thiab rov ua hauj lwm, tshem tawm kev sib cais coob, txo kev nyuaj siab ntawm tus neeg, thiab ntseeg tau kev npog ruaj khov.

4. Kev Siv Dav Dav

Haum rau cov khoom siab viscosity, me me, corrosion, thiab yooj yim contaminated los ntawm kev hloov ntaub npog khoom siv thiab vacuum siab. "Thin-layer filtration" design ua hauj lwm zoo rau cov khoom npog nyuaj, tiv thaiv downtime teeb meem uas feem ntau nyob rau hauv cov khoom xub dua.

5. Cov Nqi Kho Tsawg

Cov khoom tseem ceeb siv cov khoom wear-resistant thiab corrosion-resistant. Modular design yooj yim rau kev kho ib feem ib feem, txo downtime. Ntaub npog siv dua txo kev hloov khoom noj khoom hnav, nrog lub neej siv 8-10 xyoo nyob rau hauv kev kho zoo.

Cov Lus Qhia Parameter

Npe parameter	Kev sib txawv/qhov tseem ceeb
Chaw npog	Me: 2-60㎡ Loj: 60-120㎡ Kev cai: ≤150㎡
Dav ntawm ncauj npog	500mm-3200mm， Feem ntau siv 1000mm、2000mm、3000mm
Khoom siv ncauj npog	Roj hmab corrosion resistant (kev ua hauj lwm ib txog), fluororubber (corrosion siab), roj hmab khoom noj (kev lag luam khoom noj)
Ceev ntawm ncauj npog	0.5-5m/min
Ntev ntawm tshuab	Me: 4-10m Loj: 15-35m
Dav ntawm tshuab	Ncauj npog dav 100-300mm
Siab ntawm tshuab	1.5-3m
Hnyav ntawm tshuab	2-60㎡hom: 3.0-25.6t Tshij 60㎡: 30-80t
Kev vacuum	-0.06MPa to - 0.095MPa
Lois tshuab vacuum	Me: 5.5-15kW Loj: 37-75kW
Kev ua peev xwm (kua nrig loj me)	5-200m³/h
Kev ua peev xwm (khoom qhuav tawm)	0.5-50t/h
Kev qhuav ntawm khoom nrig	15%-30%
Kev siv dej ntxuav	0.5-3m³/h
Kev ntxuav zoo	Ib txog ≥ 95%, kev ua hauj lwm zoo (tshuaj huv si) ≥ 99.8%
Fais fab voltage	380V (peb theem tsib xov); Tshuab loj xav tau fais fab siab kev cai (xws li 6kV)
Kub thaum ua hauj lwm	-10℃-40℃
Av npuas thaum ua hauj lwm	≤ 90% (tsis muaj dej condensed)
Kev tiv thaiv corrosion	Hom ib txog: tiv thaiv corrosion me me; Hom kev cai (316L stainless steel): tiv thaiv corrosion siab
Siab ntawm tshuab muab khoom	≥ 10m
Loj me ntawm dav kua npog	≥10minutefiltrateproductionofequipment

Kev Siv ntawm Tshuab Npog Vacuum Sawv Ntawm

Siv nws cov zoo ntawm kev sib cais tsis nres, kev ntxuav zoo, thiab kev haum rau cov khoom sib txawv, cov tshuab pab cov xwm txheej tseem ceeb nyob ntau kev lag luam, tshwj xeeb li no

Cheeb Tsam Kho ib Puag Nyuam

· Kev qhuav cov kua quis kev lag luam: Txo cov kua quis qhuav los ntawm 95%+ mus 25%-30%, ua kom loj me txo thiab cawm nyiaj;

· Kev ua desulfurization gypsum: Sib cais gypsum kua mus rau gypsum qhuav nrog 15%-20% kev qhuav rau khoom siv tsev;

· Kev qhuav cov kua quis urban: Kev kho automatically ntawm cov kua quis urban tiv thaiv kev contaminated thiab pab kev tso tom qab.

Cheeb Tsam Kho Zeb Thiab Metallurgy

· Kev ua mineral concentrate: Ntxuav + qhuav kom tshem cov tshuaj, txo kev qhuav mus 20%-25% thiab txhawb smelting zoo;

· Kev phaj tailings qhuav: Kev qhuav tailings kua los ntawm 5%-15% solids mus 25%-30%, txo cov nqi thiab kev phis xyoo;

· Kev rov smelting slag: Kev sib cais leaching residues thiab anode sludge kom rov tau cov metals, ua kom qhuav tso tawm.

Cheeb Tsam Tshuaj Thiab Kho Mob

· Kev huv si ntawm khoom tshuaj: Kev ntxuav coob theem tshem cov khoom tsis zoo, ua tiag ≥98% huv si hauv cov khoom nrig;

· Kev rov solvent: Kev sib cais solvent kua kom rov tau ethanol, acetone, lwm yam, rau kev siv dua;

· Kev sib cais kho mob chaw nruab nrab: Ua raws li GMP standards siv 316L stainless steel + ntaub npog khoom noj rau kev sib cais automatically tsis muaj khas.

Cheeb Tsam Ua Khoom Noj

· Kev ua starch/zaub qhuav: Kev qhuav starch kua mus 25%-30%, sib cais zaub qhuav kua los ntawm raw kua kom txhawb huv si;

· Kev ua txiv hmab txiv lws: Kev rov thiab qhuav cov txiv hmab txiv lws rau zaub tsiaj lossis cov fiber khoom noj;

· Kev pab ua mis: Kev kho whey protein residue thiab cheese khoom nrig kom ua raws li kev nyab xeeb khoom noj.

Cheeb Tsam Khoom Siv Tsev Thiab Ntawv

· Kev npaj khoom siv tsev: Kev qhuav cov khoom raw rau kiln ua dua lossis tsim duab;

· Kev rov cov khoom tsaus ntuj ntawm ntawv: Kev qhuav white mud rau kev siv filler lossis khoom siv tsev;

· Khoom siv tsev tshiab: Kev qhuav fly ash thiab slag rau kev tsim phaj ntaub.

Lwm Kev Siv Tshwj Xeeb

· Khoom siv zog tshiab: Kev ua lithium battery kua (xws li lithium iron phosphate) kom tswj kev qhuav thiab huv si;

· Kev sib cais hiav txwv dej: Kev sib cais crystallized salts los ntawm brine rau kev qhuav thiab rov;

· Coatings/pigments: Kev sib cais kua kom tshem cov solvent thiab txhawb khoom huv si.
